Pen-drawing and cutting plotter with an automatic plotting&cutting head recommended for preparation of patterns made of cardboard with max thickness of 3mm. Head of the plotter is equipped with a holder allowing usage of two independent tools: one used for plotting patterns descriptions and the other one for cutting of patterns outlines. The plotter is delivered with a vacuum pump (5,5kW power) which is responsible for holding cardboard firmly on cutting surface during cutting. Max cutting speed 1300mm/s. Working area: 1500x1200mm.
Cutting and plotting InvenPenCut XZ 1512 plotter
|
InvenPenCut XZ 1512 – Pen-drawing and cutting plotter |
|
|---|---|
| Effective working area size | 1500 x 1200mm |
| Cutting speed | 1300mm/s |
| Cutting speed | vacuum system |
| Types of cut materials | white cardboard, recycled cardboard, plastic sheets, etc |
| Working modes | plotting with pen, cutting using knife |
| Max thickness of cut material | 0,5-3,0mm |
| Cutting precision | < 0,05mm |
| Resolution | 0,025mm |
| Communication | RS-232, LPT |
| Data formats | HP-GL, DM-PL |
| Type of cutting tool | dragged steel knife |
| Type of pen | standard writing pen (oil-type or ball pen) |
| Main elements of the plotter | automatic cutting head, frame and cutting table, driving system, control box, control computer, vacuum pump |
| External dimensions | 2,035m×1,855m×1,26m |
| Type of driver and control | servo |
| Power supply | 230V / 50Hz 5A |
