InvenTex Import/Export and Data Conversion

Tools for import, export and conversion of data from other CAD systems

InvenTex IMP/EXP modules are handling international data exchange formats like DXF, AAMA and ASTM standards, allowing to cooperate between manufacturers owning different CAD systems. Additionally the InvenTex can also import and export models and markers saved in HPGL and ISO-Cut formats. In order to facilitate handling of import and export operations InvenTex IMP/EXP modules, as only a few on the market, give the possibility to create and adapt multiple profiles with required parameters, assigned to meet requirements of other systems. This functionality allows comfortable data exchange with all cooperants, as each of them can have correctly defined configuration profiles, assuring proper import and export of exchanged data.

InvenTex CAD/CAM is also offering additional converter modules InvenTex CNV which are utilized to read models, patterns and markers saved in native formats of Gerber, Lectra, Investronica, Assyst, Microdynamics and a few others, less popular CAD/CAM systems available on the market. Thanks to the converters the InvenTex CAD/CAM system is fully open and allows data exchange even with systems which cannot save or export data to standard formats: DXF/AAMA or ASTM. It’s a very big advantage of the InvenTex system which proves its superiority in reference to other CAD systems currently available on the market.

Import of data from standard formats

import of models, patterns and markers stored in the international formats: DXF, AAMA and ASTM
import of grading rules stored in RUL files or as an additional shape in DXF files
import of models, patterns and cutting markers in HP/GL, PLT, ISO-Cut formats
possibility to define multiple profiles to assure correct import parameters

Export of data to other CAD systems

export of models, patterns and cutting markers to the international formats: DXF, AAMA and ASTM
export of models, patterns and cutting markers to HP/GL, PLT, ISO-Cut formats
possibility to define multiple profiles to assure correct export parameters, adapted to the requirements of various CAD systems

Conversion of data from other CAD systems

import of models, patterns and cutting markers stored in native formats of Gerber, Lectra, Assyst and Investronica CAD systems
possibility to read data directly from native storage area of other system without the need to convert data to separate files
InvenTex as the only such system on the market can read and process grading by circumference and height stored as alterations in Gerber system
